Levitaz Foils, Wings & Masts

Build Your Perfect Setup

Foil Configurator

Customize your Levitaz Free Series foil to perfectly match your riding style and local conditions.

Configure Now

Levitaz Free Series

Key Benefits

Maximum efficiency meets premium quality

  • Low-maintenance interfaces, fast part replacement

    Maximized uptime and reduced Total Cost of Ownership.

  • Consistent quality & tight tolerances

    Fewer returns and higher resale value thanks to the use of premium materials.

  • Unified setup experience

    Customers can switch configurations without a learning curve.

System Overview

Free Series Front Wings

Shop Frontwing
As surface area increases, so does aspect ratio: Each size features a finely tuned outline and anhedral geometry for optimal agility and balance. Lift-to-drag ratio is precisely optimized for every application.
FW 540
SPAN // 67 cm
WING AREA // 540 cm²
ASPECT RATIO // 8.4
Extremely high top-end performance – agile and easy to control.
-
KITE // WING // BIGWAVE SURF
FW 680
SPAN // 77 cm
WING AREA // 680 cm²
ASPECT RATIO // 8.7
Versatile with a wide performance range, strong top-end and balanced turning.
-
KITE // WING // AGILE SURF
FW 790
SPAN // 90 cm
WING AREA //  790 cm²
ASPECT RATIO // 10.3
Forgiving ride characteristics with excellent glide.
-
KITE // WING // SURF
FW 900
SPAN // 110 cm
WING AREA //  900 cm²
ASPECT RATIO // 13.3
High glide performance with stiff flex.
-
WING // DOWNWIND // SUP // PUMP

FREE SERIES STABILIZER

Shop Stab
STAB 180
SPAN // 39 cm
WING AREA //  180 cm²
ASPECT RATIO // 8.6
//
One stab fits all – a universal rear wing compatible with all Free Series front wings.
//
How does it work? Front wing-specific titanium fuselages ensure identical interfaces.
//
On the water: consistent pitch stability, familiar handling, and fast front wing swaps.

FREE SERIES MASTS

Shop Mast
//
Length-specific design: customized taper, thickness profile, and layup for each size.
//
Race inspired profile: low drag, high stiffness, and precise control.
//
Hydro- and aerodynamic plate interface with slotted holes for quick mounting and fine-tuned trim adjustments.
MAST 76
LENGTH // 76 cm
MIN. THICKNESS //  16 mm
MAST 84
LENGTH // 84 cm
MIN. THICKNESS //  14,5 mm
MAST 96
LENGTH // 96 cm
MIN. THICKNESS //  13,9 mm

Interface

THE CORE - TITANIUM FUSELAGE

//
CNC-machined from high-strength titanium with ultra-tight tolerances for a play-free fit and ultra-precise power transfer.
//
Integrated into the front wing: The titanium insert is pressed in during the lamination process, creating an ultra-stiff and permanent bond.
//
Strength without weight: Delivers high torsional and bending stiffness with minimal mass and the slimmest possible profile – for outstanding hydrodynamic performance.
//
Corrosion-resistant: Saltwater-proof and minimizes galvanic reactions with carbon components.
//
Service-friendly: Durable titanium threads in the mast allow for frequent assembly cycles without wear concerns.
//
One tool for all: Both the glider and mast-to-board connections use the same T30 Torx drive – simple and efficient.

Rider Guide

Discipline Use Case 540 680 790 900
Wing
Wing Rider Type Adv-Exp Int-Adv Int Int
Rider Weight 50–85 kg 50–95 kg 65–95 kg 75–100 kg
Wind 22–35+ kn / high 16–30 kn / med-strong 12–25 kn / allround 8–20 kn / light-med
Kite
Kite Rider Type Int-Race Int-Adv Beg-Int LW / Exp
Rider Weight 50–85 kg 50–95 kg 65–95 kg 75–100 kg
Wind 6–35+ kn 6–28 kn 6–22 kn 6–15 kn (lightwind)
Downwind / SUP / Pump
Downwind / SUP Rider Type Exp DW Int-Adv Int-Adv
Rider Weight 60–85 kg 70–95 kg 75–100 kg
Wind / Swell 25–35 kn / steep - windswells 15–25 kn / ocean bumps 10–20 kn / mellow bumps
Prone / Foil Assist
Prone / Foil Assist Rider Type Adv-Pro Int-Adv Int Beg-Int
Rider Weight 60–85 kg 65–90 kg 65–90 kg 75–100 kg
Wave Big wave tow in Powerful Soft / foil assist Very small / mushy / foil assist
